PSG NOW NAD4000 Composite
Composite aluminum-foil inspection line combining metal detection and checkweighing in one extended conveyor.
Key specifications
- Tunnel Width: 450mm / 600mm
- Tunnel Height: 100 / 150 / 200 / 230mm
- Conveyor Length: 2,300mm
- Conveyor Height: 650 / 700 / 750 / 800mm
- Configuration: Metal detector + checkweigher
- Power: 220V, 50/60Hz, single phase
The PSG NOW NAD4000 Composite is a combined inspection line that integrates aluminum-foil metal detection with checkweighing on a single extended 2,300mm conveyor. It handles larger formats with tunnel widths up to 600mm and pass heights up to 230mm, providing simultaneous contamination detection and weight verification for aluminum-packaged products in one footprint.
