SN FMH 300
High-hygienic triplex HFFS rotary machine making three pouches 115–194 mm wide per cycle, at up to 270 a minute for long washdown runs.
Key specifications
- Type: Intermittent HFFS Rotary
- Stations: 8 (optional 10)
- Design: High-Hygienic (wash down)
- Configuration: Triplex
- Max. Output: Up to 270 pouches/min
- Pouch Width: 115 – 194 mm
- Pouch Length: 80 – 350 mm
- Power: 30 kVA
The SN FMH 300 is the triplex model in SN's Hygienic Series, making three pouches per cycle at up to 270 pouches a minute. Pouches can be 115–194 mm wide and 80–350 mm long, a narrower window than the duplex FMH 200's 150–308 mm, in exchange for 50% more output. That balance fits long production runs of mid-width pouches in hygienically demanding areas such as dairy, cheese and pet food. The stainless steel washdown frame, servo-driven unwinding and recipe management come as standard. For even more output on pouches up to 137 mm wide, the quadruplex FMH 400 reaches 360 a minute.
Industries served
- Food packaging
- Pet Food packaging
- Pharmaceutical packaging
- Cosmetics & Personal Care packaging
- Cheese & Dairy packaging
