SN M 40
Horizontal form-fill-seal machine from SN's Seed Series, forming and filling seed pouches 60–150 mm wide at up to 120 pouches a minute.
Key specifications
- Type: Intermittent HFFS
- Machine Type: Horizontal form, fill, and seal machine (HFFS)
- Configuration: Simplex
- Max. Output: Up to 120 pouches/min
- Pouch Width: 60 – 150 mm
- Pouch Height: 70 – 220 mm
- Power: approx. 2.0 kVA
The SN M 40 is the horizontal form, fill and seal machine in SN's Seed Series. It forms pouches 60–150 mm wide and 70–220 mm tall and fills them with seed at up to 120 pouches a minute, the highest rate in the series. Like the vertical FBV 80-120, it takes several seed dosing units, so changing to the next variety takes a few minutes and largely no tools. It shares the FBV's footprint of about 2,500 × 1,200 mm but stands lower, at about 2,000 mm tall against 2,500 mm. Recyclable mono-materials, including plastic and grass paper, can be processed, and the M 40 is also one of the two machines in
